Product Description
|
item
|
value
|
|
Place of Origin
|
China
|
|
Brand Name
|
Polyester Film
|
|
Model Number
|
60210/6021
|
|
Type
|
Polyester Film
|
|
Material
|
PET
|
|
Application
|
High Temperature
|
|
Color
|
Milky White/transparent
|
|
Size
|
1000m
|
Description of Polyester Film
Polyester film - (PET Film) exhibits superior strength, heat resistance, and excellent insulating properties. The unique qualities
of Mylar film (PET Film) created new consumer markets in magnetic audio and video tape, capacitor dielectrics, packaging, and
batteries.
Polyester Film is made from Polyethylene terephthalate by casting & Biaxially oriented.
About the polyester film, Yanan has two different types:
6020-Polyester Film For Electrical Insulation (Transparent)
6021-Polyester Film For Electrical Insulation (Milky white)
The different between the 6020 and 6021:
6020/6021 polyester film is biaxially oriented polyethylene terephthalate (PET)film.6020 is transparent film,6021 is milky white.
6020 polyester film always as a laminate with other substrates.6021 can be used as an electrical insulation directly, it has good
dielectrical and high mechanical properties.
Features of the Polyester Film
Good mechanical properties and folding tolerance
Resistant to oil, fat, dilute acid and alkali, most solvent.
Has excellent temperature tolerance.
Low gas and vapor permeability, and good resistance to gas, water,
oil and odor.
High transparency and glossy, also can block ultraviolet ray.
Can be directly used in food packing since it is non-toxic, unscented with good sanitary security.
Model: 6020,6021
Insulation class:E Class (120)
Color6020 transparent6021 translucent
Width: 1010mm
Thickness:0.025mm-0.35mm
The Class E 6020 transparent and 6021 translucent polyester film have been approved by UL (NO.: E310670) ,ROHS and REACH test.
Applications
Widely used for the end wrap insulation
Liner insulation of electrical oils
Electromagnetic wire wrap insulation
Cable wrapping on motor
Transformer or other electrical appliances
It also be used for packaging, glass-steel, collar of clothes, etc
Versatile Polyester Film SolutionsOur Polyester Film is engineered for strength, clarity, and adaptability. It is ideal for packaging, labeling, and craft purposes, thanks to its stable surface and resistance to tearing. The combination of polyester and wood pulp creates a balance between flexibility and durability, making it suitable for a wide range of industrial uses.
Available Options and SpecificationsChoose from transparent or white films, tailored in standard sizes and thicknesses between 8 and 50 mm. Each roll is finished with a coating that enhances performance, whether for protective, decorative, or printed applications. Replacement is supported by a product warranty for customer assurance.
FAQs of Polyester Film:
Q: How is polyester film used across different industries?
A: Polyester film is widely utilized in packaging, printing, electrical insulation, and lamination due to its strength, clarity, and chemical resistance. The addition of wood pulp makes some variants especially suitable for craft and specialty applications.
Q: What is the manufacturing process for coated polyester film?
A: Coated polyester film is produced by extruding melted polyester resin onto a flat surface, cooling and stretching it to the desired thickness, and then applying a specialized coating to enhance properties like adhesion or moisture resistance.
Q: When should I choose transparent versus white polyester film?
A: Select transparent polyester film when visibility of contents, clarity, or decorative effects are important. Opt for white polyester film for opacity, added protection from light, or when a printable surface is needed for labels and graphics.
Q: Where can I purchase polyester film in India?
A: Polyester film can be sourced directly from us as a distributor, supplier, exporter, importer, manufacturer, and trader in India, ensuring prompt delivery and expert support for your project needs.
Q: What are the main benefits of using polyester film with wood pulp?
A: Polyester film with wood pulp offers improved flexibility, enhanced printability, and increased tear resistance, making it perfect for demanding craft, laminating, and specialty paper applications.
Q: How does the warranty on polyester film products work?
A: All our polyester films come with a warranty that covers manufacturing defects. For further assistance regarding claims or product support, customers can contact our sales or service department.
